LOCUS XBTx

ADAPTIVE X-BAND TRANSMITTER

LOCUS XBTx - ASELSAN

LOCUS XBTx

LOCUS XBTx (Adaptive X-Band Transmitter) developed by ASELSAN for transmission of the payload data from LEO Earth Observation Satellites to ground stations.

General Features

LOCUS XBTx General Features

  • Acquisition and reception of payload data
  • Modulation and coding
  • Digital to analog conversion
  • RF upconversion, amplification and filtering

Brochure

LOCUS XBTx

Contents:

  • Bus Voltage : Unregulated between 22 VDC and 38 VDC
  • Power consumption : < 20 W
  • Dimensions : < 240 x 110 x 170 mm3 (WxLxH)
  • Mass : < 2.5 kg
